Vibrating Screen - Carbon Steel
Product Highlights
Highly energy-efficient, stable, reliable, and cost-effective; durable with high load capacity; simple to operate and easy to maintain; adjustable screening throughput.
Application Scope
Widely used for screening and grading of powders, granules, and small lumps in industries such as mining, building materials, metallurgy, general chemical processing, and aggregate production.
Suitable Materials
Non-corrosive powders and granular materials such as mineral powder, sand and gravel, coal, quartz sand, ordinary chemical granules, metal powders, and building material powders.
How it works
Equipped with advanced vibration motor drive technology, this system achieves precise screening and grading by adjusting excitation force and amplitude. Its compact structure ensures smooth operation with low energy consumption. The high-strength carbon steel frame is ideal for heavy-duty industrial screening applications.
Use Cases
Proven across multiple industries and material scenarios.
Food Industry
Carbon steel rusts easily and is generally not used for directly screening food ingredients. It is mostly employed in downstream, non-product-contact stations and rarely handles food powders directly.
Chemical Industry
Low cost; ideal for sieving and purifying dry, non-corrosive general chemical materials. Avoid use with wet or highly corrosive materials to prevent rust contamination of the product.
Mining
High strength and cost-effective; widely used for dry material screening and impurity removal in mining, suitable for scenarios allowing minor iron contamination.
Feed industry
Carbon steel is prone to rusting and shedding debris; it is generally not used for direct screening of feed raw materials. It may only be employed in non-product-contact auxiliary processes downstream.
Building Materials Industry
Industry-standard selection for construction materials: high strength, low cost. Classifies and removes impurities from powdered granules; ideal for drying building materials.
Environmental Industry
Handles dry, eco-friendly solid waste granules and powders. Robust equipment with significant cost advantages; not suitable for wet or corrosive solid waste.
Technical Reference
Detailed technical specifications and product details
Technical Specifications
Technical Reference
| Sifting Capacity | 5-6000 kg/h, dynamically adjusted based on material density, mesh size, and number of screening layers |
| Total Power of Vibrating Motor | 0.75-1 1kW, single or dual motor drive options with variable frequency speed control |
| Screen Diameter | 400-2000mm, compatible with all standard models |
| Device dimensions (length × width) | Customizable based on screen diameter and number of layers. |
| Core Material | Q235A/B Carbon Structural Steel, all-carbon steel welded structure; contact surfaces with materials can be customized with high-manganese steel wear-resistant lining. |
| Filter layers | 1-6 layers available for 2-7 level precision screening |
| Screen Mesh Specifications | Custom 20-800 mesh; supports manganese steel perforated screens, stainless steel woven screens, and wear-resistant polyurethane screen panels. |
| Vibration Frequency | 1500r/min, supports variable frequency speed control and allows adjustment of vibration parameters as needed. |
| Amplitude | 0.5-8mm: Adjustable eccentric blocks for screening heavy and large-particle materials. |
| Net Cleaning Device | Bouncing Ball, Ultrasonic, and Brush Cleaning Systems: Prevent Screen Blinding and Boost Screening Efficiency |
| Surface Finish | The entire body undergoes rust removal, acid pickling, and phosphating treatment. It is equipped with anti-rust primer plus industrial topcoat. Wear-resistant and anti-corrosion coatings are available as custom options. |
| Sealing structure | Fully sealed dust-proof design with optional oil, acid, and alkali-resistant rubber seals for high-dust and corrosive environments. |
| Explosion-proof rating | Standard non-explosion-proof version; optional Ex d IIB T4 Gb fully explosion-proof version for hazardous environments in chemical and mining industries. |
| Control Method | Optional: standard relay control or fully automated PLC + HMI control. Supports start/stop linkage, vibration parameter adjustment, and overload/clogging fault alarms. |
| Suitable Materials | Ideal for screening, grading, impurity removal, and mud dewatering of powders, granules, and small lumps in industries such as construction materials, mining, metallurgy, chemicals, aggregates, abrasives, and recycling—where sanitary-grade requirements are not applicable. |
